Product Details:
|
| Features: | Technical Specification | Processor: | Up To Four 2nd Generation Intel® Xeon® Scalable Processors, Up To 28 Cores Each |
|---|---|---|---|
| Memory: | 48 DDR4 DIMM Slots, Supports RDIMM /LRDIMM, Up To 2933MT/s, 6TB Max Up To 12 NVDIMM, 384GB Max Up To 24 Intel® Optane™ DC Persistent Memory PMem, Max 12.28TB, (15.36TB Max With PMem And LRDIMM) | Storage Controllers: | Internal Controllers: PERC H330, H730P, H740P, HBA330 |
| Drive Bays: | Front Drive Bays: Up To 8 X 2.5” SAS SATA (HDDs/SSDs) Max 61.44TB, Or Up To 24 X 2.5” SAS/SATA (HDDs/SSDs) With Up To 12 NVMe PCIe SSDs Max 184.32TB, Or Up To 24 NVMe PCIe SSDs Max 153TB Rear Drive Bays: Up To 2 X 2.5” SAS/SATA (HDDs/SSDs), Max 15.36TB | Power Supplies: | Gold:1100W - 48VDC, Platinum: 750W, 750W 240VDC2 , 1100W, 1100W 240VDC1 1600W, 2000W, 2400W |
| Highlight: | 8 Bay 2u Rackmount Server,PowerEdge R840 2u Rackmount Server,EMC R840 Dell Poweredge Server |
||
POWEREDGE R840 Turbocharge your data analytics Designed to drive faster insights, the PowerEdge R840 delivers four-socket performance in a dense 2U design. Power your business-critical workloads with up to 24 direct-attached NVMe drives.
Maximize performance for demanding workloads The R840 delivers consistent, high performance results for data-intensive applications and data analytic workloads. With powerful 2nd Generation Intel® Xeon® Scalable processors and up to 112 cores, the R840 can quickly turn analytics into insights to drive your business forward faster. Create an optimal configuration of NVMe, SSD, HDD and GPU resources to address your most demanding workloads - all in a 2U chassis. • Scale capacity and performance with up to 26 2.5” HDDs and SSDs, 62% more than the previous generation.1 • Accelerate applications with up to 2 double-width GPUs or up to 2 FPGAs. • Speed data transfers with a fully integrated ultra path interconnect across all four sockets. • Eliminate bottlenecks with up to 48 DIMMs, including up to 24 PMems or 12 NVDIMMs. Automate everyday tasks with Dell EMC OpenManage The Dell EMC OpenManage™ portfolio helps deliver peak efficiency for PowerEdge server customers, delivering intelligent, automated management of routine tasks. Combined with unique agent-free management capabilities, the R840 is easy to manage, and by doing routine work automatically, you can free up time for higher-value projects. • Unify monitoring and management of your IT infrastructure with OpenManage Enterprise. • Utilize a variety of OpenManage integrations and connections to take advantage of your existing IT management platform. • Take advantage of QuickSync 2 capabilities and gain access to your servers easily through your phone or tablet. Safeguard your data center with built-in security Every PowerEdge server is made with a cyber-resilient architecture, delivering security into all parts of a server’s life cycle. The R840 uses these new security features so you can reliably and securely deliver the right data to where your customers are, no matter where they are. Dell EMC considers each part of system security, from design to end of life, to ensure trust and deliver worry-free systems
| DELL R840 | |
| Processor | Up to four 2nd Generation Intel® Xeon® Scalable processors, up to 28 cores each |
| Memory | 48 DDR4 DIMM slots, Supports RDIMM /LRDIMM, up to 2933MT/s, 6TB max Up to 12 NVDIMM, 384GB Max Up to 24 Intel® Optane™ DC persistent memory PMem, max 12.28TB, (15.36TB max with PMem and LRDIMM) Supports registered ECC DDR4 DIMMs only |
| Storage controllers Internal Boot | Internal Controllers: PERC H330, H730P, H740P, HBA330 External Controllers: H840, 12 Gbps SAS HBA Software RAID:S140 |
| Storage | Front drive bays: Up to 8 x 2.5” SAS/SATA (HDD/SSD) max 122.88TB or up to 8 x 2.5” SAS/SATA HDD max 128TB Optional DVD-ROM, DVD+RW |
| Drive bays | Front drive bays: Up to 8 x 2.5” SAS SATA (HDDs/SSDs) max 61.44TB, or up to 24 x 2.5” SAS/SATA (HDDs/SSDs) with up to 12 NVMe PCIe SSDs max 184.32TB, or up to 24 NVMe PCIe SSDs max 153TB Rear drive bays: Up to 2 x 2.5” SAS/SATA (HDDs/SSDs), max 15.36TB |
| Power supplies | :1100W - 48VDC, Platinum: 750W, 750W 240VDC2 , 1100W, 1100W 240VDC1 1600W, 2000W, 2400W |
| Dimensions | Height: 86.8mm (3.4”) Width*: 434.0mm (17.08”) Depth*: 835.9mm (32.9”) Weight: 36.6kg (80.7lbs.) *Dimensions do not include bezel, brackets or PSU handles |
| Embedded management | iDRAC9, iDRAC Direct, iDRAC RESTful with Redfish, Quick Sync 2 wireless module (optional) |
| Bezel | Optional LCD Bezel or Security bezel |
| OpenManage™ Software | OpenManage Enterprise OpenManage Mobile OpenManage Power Manager |
| I/O & Ports |
Rear ports: 1 x Dedicated iDRAC port, 1 x Serial, 2 x USB 3.0, 1 x VGA Internal port: 1 x USB 3.0 Video card: 2 x VGA PCIe: Up to 6 x Gen3 slots, (4x16 slots or 2x16 + 4x8 slots) |
