Product Details:
|
| Features: | Technical Specification | Processor: | Up To Two 2nd Generation Intel® Xeon® Scalable Processors, Up To 28 Cores Per Processor |
|---|---|---|---|
| Memory: | 24 DDR4 DIMM Slots, Supports RDIMM /LRDIMM, Speeds Up To 3200MT/s, 3TB | Storage Controllers: | Internal Controllers: PERC H330, H730P, H740P, HBA330 |
| Drive Bays: | 12 X 3.5” SAS/SATA HDD Max 216TB | Payment Solutions Provided And Serviced By Dell Financial Services L.L.C Or Its Affiliate Or Designe: | Titanium 750W, Platinum 495W, 110W |
| Highlight: | Dell Poweredge Server R740XD,Dell Poweredge Server 12*3.5,2u Poweredge R740xd Server |
||
POWEREDGE R740xd Maximize storage performance and scalability The PowerEdge R740xd delivers a perfect balance between storage scalability and performance. The 2U two-socket platform is ideal for software defined storage, service providers or as virtual desktop infrastructure.
Maximize performance and capacity The scalable system architecture behind the R740xd with up to 24 NVMe drives creates the ideal balance between scalability and performance. The R740xd versatility is highlighted with the ability to mix any drive type to create the optimum configuration of NVMe, SSD and HDD for either performance, capacity or both. The R740xd is the platform of choice for software defined storage and is the foundation for VSAN or the PowerEdge XC. • Maximize storage performance with up to 24 NVMe drives and ensure application performance scales to meet demands. • Free up storage space using internal M.2 SSDs optimized for boot. • Simplify and accelerate ScaleIO or VMware vSAN™ deployments with validated, pre-bundled and tailored Ready Nodes. • Accelerate workloads with up to three double-width 300W GPUs, or up to six single-width 150W GPUs, or up to three double-width or up to four single-width FPGAs. Automate maintenance with Dell EMC OpenManage Dell EMC PowerEdge servers with OpenManage™ technology work at peak efficiency for PowerEdge servers, delivering intelligent, automated management of routine tasks. Combined with unique agent-free management capabilities, the R740xd is simply managed, freeing up time for high profile projects. • Simplify management with the OpenManage EnterpriseTM console, with customized reporting and automatic discovery. • Take advantage of QuickSync 2 capabilities and gain access to your servers easily through your phone or tablet.
| DELL R740XD | |
| Processor | Up to two 2nd Generation Intel® Xeon® Scalable processors, up to 28 cores per processor |
| Memory | 24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2933MT/s, 3TB max Up to 12 NVDIMM, 192 GB Max Up to 12 Intel® Optane™ DC persistent memory PMem, 6.14TB max, (7.68TB max with DPCMM + LRDIMM) Supports registered ECC DDR4 DIMMs only |
| Storage controllers Internal Boot | Internal Controllers: PERC H330, H730P, H740P, HBA330 External Controllers: H840, 12 Gbps SAS HBA Software RAID:S140 Boot Optimized Storage Subsystem (BOSS):HWRAID 2 x M.2 SSDs 240GB, 480GB Internal Dual SD Module1 |
| Storage | Front drive bays: Up to 16 x 2.5” SAS/SATA (HDD/SSD) max 122.88TB or up to 8 x 3.5” SAS/SATA HDD max 128TB Optional DVD-ROM, DVD+RW |
| Drive bays | Front bays: Up to 24 x 2.5” SAS/SATA (HDD/SSD), NVMe SSD max 184.32TB or up to 12 x 3.5” SAS/SATA HDD max 216TB Mid bay: Up to 4 x 2.5”, max 30.72TB SAS/SATA (HDD/SSD), or up to 4 x 3.5” SAS/SATA HDD, max 64TB Rear bays: Up to 4 x 2.5”, max 30.72TB SAS/SATA (HDD/SSD), or up to 2 x 3.5” SAS/SATA HDD max 32TB |
| Power supplies | Titanium 750W, Platinum 495W, 750W, 750W 240VDC,* 1100W, 1100W 380VDC* 1600W, 2000W and 2400W, Gold 1100W |
| Dimensions | Form factor: Rack (1U)Height: 42.8mm (1.69”) Width*: 482.0mm (18.98”) Depth*: 808.5mm (31.8”) Weight: 21.9kg (48.3 lbs.) *Dimensions include bezel. |
| Embedded management | iDRAC9, iDRAC Direct, iDRAC RESTful API with Redfish Quick Sync 2 wireless module (optional) |
| Bezel | Optional LCD Bezel or Security bezel |
| OpenManage™ Software | OpenManage Enterprise OpenManage Mobile OpenManage Power Manager |
| I/O & Ports | Network daughter card options 4 x 1GbE or 2 x 10GbE + 2 x 1GbE or 4 x 10GbE or 2 x 25GbE Front ports: 1 x Dedicated iDRAC Direct Micro-USB, 2 x USB 2.0, 1 x USB 3.0 (optional) 1 x VGA Rear ports: 1 x Dedicated iDRAC network port, 1 x Serial, 2 x USB 3.0, 1 x VGA Video card: 2 x VGA Riser options with up to 8 PCIe Gen 3 slots, maximum of 4 x 16 slots |
Notices:
1. Open the packaging, check the products carefully, and take them gently.
2. The product is a brand new original unopened equipment.
3. All products 3 year warranty, and the buyer is responsible for the return shipping cost.
International Buyers Please Note:
Import duties, taxes, and charges are not included in the item price or shipping cost. These charges are the buyer's responsibility.
Please check with your country's customs office to determine what these additional costs will be prior to bidding or buying.
Customs fees are normally charged by the shipping company or collected when you pick the item up. These fees are not additional shipping charges.
We won't under-value merchandise or mark the item as a gift on customs forms. Doing that is against U.S. and international laws.
Customs delays are not the responsibility of the seller.
Contact Person: Sandy Yang
Tel: 13426366826
