Product Details:
|
| Model: | FusionServer 2488HV5 | Processors: | One Or Two 3rd Gen Intel® Xeon® Scalable Ice Lake Processors (8300/6300/5300/4300 Series), Thermal Design Power (TDP) Up |
|---|---|---|---|
| Memory: | 48 DDR4 DIMM Slots, 2,933 MT/s; Up To 24 Intel® Optane™ PMem Modules (100 Series), 2666 MT/s | Local Storage: | Supports Various Drive Configurations And Hot Swappable: • 10 X 2.5-inch Drives (6–10 NVMe SSDs And 0–4 SAS/SATA Drives, With A Total Number Of 10 Or Less) • 10 X 2.5-inch Drives (2–4 NVMe SSDs And 6–8 SAS/SATA Drives, With A Total Number Of 10 Or Less) • |
| RAID Support: | Supports RAID 0, 1, 10, 5, 50, 6, Or 60, Optional Supercapacitor For Cache Data Power Failure Protection, RAID Level Migration, | Power Supply: | • 900 W AC Platinum/Titanium PSUs (input: 100 V To 240 V AC, Or 192 V To 288 V DC) • 1500 W AC Platinum PSUs 1000 W (input: 100 V To 127 V AC) 1500 W (input: 200 V To 240 V AC, Or 192 V To 288 V DC) • 1500 W 380 V HVDC PSUs (input: 260 V To 400 V DC) • 120 |
| Highlight: | Original Huawei Fusionserver 2488h V5,Huawei 2488H V5 Server 2u Rack,Intel Xeon Server 2u Rack |
||
Product Introduction
The FusionServer 2488H V5 is a 2U, 4-socket rack server, ideal for virtualization, HPC, database, and SAP HANA. In a virtualization application, one FusionServer 2488H V5 reduces OPEX by about 32 percent compared with two traditional 2U, 2S rack servers. The 2488H V5 supports 4 Intel® Xeon® Scalable processors in a 2U space, up to 48 DDR4 DIMMs, and up to 25 x 2.5-inch hard drives for local storage (configurable with 8 NVMe SSDs). It incorporates patented technologies, such as Dynamic Energy Management Technology (DEMT) and Fault Diagnosis & Management (FDM), and integrates FusionDirector software for entire-lifecycle management, helping customers drive down OPEX and improve Return On Investment (ROI). * Source: Test results from Global Computing Innovation OpenLab, Q2 2017.
Technical Specifications
| Specification Name | Specifications |
|---|---|
| Model | FusionServer 2488H V5 |
| Form Factor | 2U rack server |
| Processors |
2 or 4 1st Generation Intel® Xeon® Scalable processors (5100/6100/8100 series), up to 205 W 2 or 4 2nd Generation Intel® Xeon® Scalable processors (5200/6200/8200 series), up to 205 W |
| Memory | 48 DDR4 DIMM slots, 2,933 MT/s; up to 24 Intel® Optane™ PMem modules (100 series), 2666 MT/s |
| Internal Storage |
Supports the following hard drive configuration options: 8 x 2.5-inch SAS/SATA HDDs on the front 25 x 2.5-inch SAS/SATA HDDs on the front 24 x 2.5-inch SAS/SATA HDDs on the front 8 x 2.5-inch NVMe SSDs and 16 x 2.5-inch SAS/SATA HDDs on the front 24 x 2.5-inch NVMe SSDs Supports flash storage: 2 M.2 SSDs |
| RAID Support |
Supports RAID 0, 1, 5, 6, 10, 50, or 60 Supports a supercapacitor for cache power-off protection Supports functions such as RAID level migration, drive roaming |
| LOM Network Ports | 2 x GE + 2 x 10 GE ports |
| PCIe Expansion | Up to 11 PCIe 3.0 slots |
| Fan Modules | 4 hot-swappable fan modules with optional N+1 redundancy |
| Power Supply Units |
hot-swappable PSUs, with support for 1+1 redundancy. The following PSUs are supported: 2,000W AC Platinum PSUs 1,500W AC Platinum PSUs 900W AC Platinum PSUs 1,200W DC PSUs |
| Management |
iBMC integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis, automated O&M, and hardware security hardening iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management interface based on HTML5/VNC KVM; supports CD-free deployment and the Agentless feature, simplifying management (Optional) Configured with the FusionDirector management software to provide advanced management features such as stateless computing, batch OS deployment, and automated firmware upgrade, enabling smart and automatic entire-lifecycle management |
| Operating Temperature | 5°C to 45°C (41°F to 113°F), compliant with ASHRAE Classes A3 and A4 |
| Certifications | CE, UL, FCC, CCC, and RoHS |
| Installation Suite | L-shaped guide rails, adjustable guide rails, and holding rails |
| Dimensions (H x W x D) | 86.1 mm (2U) x 447 mm x 748 mm (3.39 in. x 17.60 in. x 29.45 in.) |
