Product Details:
|
| Switching Capacity: | 104Gbps | Box Switching Capacity: | 598Gbps |
|---|---|---|---|
| Packet Forwarding Rate:: | 78 Mpps | CPU:: | 1 Core, 800MHz |
| Flash/SDRAM:: | 512MB/512MB | Management Ethernet Ports: | 1 |
| Highlight: | S5560S-28S-EI H3c Server,24 Port Gigabit H3c Server,S5560S-28S-EI Server H3c |
||
H3C S5560S-28S-EI 24 Gigabit electrical port 40000 Gigabit optical port aggregation Layer 3 core switch
H3C S5560S-EI Series Enhanced Gigabit Switches
H3C S5560S-EI Switch Series is robust (modular dual power), and easy to deploy Layer 3 access switching solution that offers enhanced security and 10GbE uplinks, BGP and Multicast, SDN and IRF enabled, flexible management.
It offers the following benefits:
Rich layer 3 features with H3C's state-of-the-art Comware 7 operating system.
Reliable hardware design with modular dual power supply.
Embedded SmartMC delivers the easiest and simplest network operation and management solution.
High-density 10/100/1000Base-T autosensing Ethernet ports and GE/10GE SFP + fiber ports onboard
As an access device on enterprise networks, this switch can provide high-density GE connections for desktop applications.
The S5560S-EI switch series has the following models:
S5560S-28S-EI—Provides 24 × 10/100/1000BASE-T ports (including 8 × combo interfaces) and 4 × 10G/1G BASE-X SFP+ ports.
S5560S-52S-EI—Provides 48 × 10/100/1000BASE-T ports and 4 × 10G/1G BASE-X SFP+ ports.
S5560S-28S-PWR-EI—Provides 24 × 10/100/1000BASE-T ports (including 4 × combo interfaces) and 4 × 10G/1G BASE-X SFP+ ports.
S5560S-52S-PWR-EI—Provides 48 × 10/100/1000BASE-T ports and 4 × 10G/1G BASE-X SFP+ ports.
S5560S-28P-EI—Provides 24 × 10/100/1000BASE-T ports (including 8 × combo interfaces) and 4 × SFP ports.
S5560S-52P-EI—Provides 48 × 10/100/1000BASE-T ports and 4 × SFP ports.
S5560S-28F-EI—Provides 24 ×SFP ports (including 8 × combo interfaces) and 4 × SFP+ ports.
S5560S-52F-EI—Provides 48 ×SFP ports (including 2 × combo interfaces) and 4 × SFP+ ports.
Specification
| Item | S5560S-28S-EI | S5560S-52S-EI | S5560S-28P-EI | S5560S-52P-EI |
| Port Switching capacity | 128Gbps | 176Gbps | 56Gbps | 104Gbps |
| Box Switching capacity | 598Gbps | |||
| Packet forwarding rate | 96 Mpps | 132 Mpps | 42 Mpps | 78 Mpps |
| CPU | 1 Core, 800MHz | |||
| Dimensions (H × W × D) | 43.6 × 440 × 360 mm (1.72 × 17.32 × 14.17 in) | 43.6 × 440 × 360 mm (1.72 × 17.32 × 14.17 in) | 43.6 × 440 × 360 mm (1.72 × 17.32 × 14.17 in) | 43.6 × 440 × 360 mm (1.72 × 17.32 × 14.17 in) |
| Weight | ≤ 8 kg (17.64 lb) | ≤ 8.5 kg (18.74 lb) | ≤ 8 kg (17.64 lb) | ≤ 8.5 kg (18.74 lb) |
| Flash/SDRAM | 512MB/512MB | |||
| Management Ethernet ports | 1 | |||
| Console ports |
1 × RJ-45 console port 1 × Micro-USB port Only the Micro-USB port is available if you connect both ports. |
|||
| Service ports |
24 × 10/100/1000Base-T autosensing Ethernet ports (including 8 combo interfaces) 4 × 10G SFP+ ports |
48 × 10/100/1000Base-T autosensing Ethernet ports 4 × 10G SFP+ ports |
24 × 10/100/1000Base-T autosensing Ethernet ports (including 8 combo interfaces) 4 × GE SFP ports |
48 × 10/100/1000Base-T autosensing Ethernet ports 4 × GE SFP ports |
| Stacking bandwidth | 80Gbps | 16Gbps | ||
| Rated input voltage |
AC: 100 VAC to 240 VAC @ 50 Hz/60 Hz DC: –36 VDC to –72 VDC |
|||
| Min. power consumption |
Single 75 W AC inputs: 12 W Dual 75 W AC inputs: 14 W Single 150 W AC input: 16 W Dual 150 W AC inputs: 22 W Single 150 W DC input: 15 W Dual 150 W DC inputs: 21 W |
Single 75 W AC input: 21 W Dual 75 W AC inputs: 24 W Single 150 W AC input: 25 W Dual 150 W AC inputs: 30 W Single 150 W DC input: 26 W Dual 150 W DC inputs: 32 W |
Single 75 W AC input: 12 W Dual 75 W AC inputs: 13 W Single 150 W AC input: 15 W Dual 150 W AC inputs: 20 W Single 150 W DC input: 15 W Dual 150 W DC inputs: 21 W |
Single 75 W AC input: 21 W Dual 75 W AC inputs: 23 W Single 150 W AC input: 24 W Dual 150 W AC inputs: 29 W Single 150 W DC input: 25 W Dual 150 W DC inputs: 30 W |
| Max. power consumption |
Single 75 W AC input: 33 W Dual 75 W AC inputs: 36 W Single 150 W AC input: 35 W Dual 150 W AC inputs: 42 W Single 150 W DC input: 40 W Dual 150 W DC inputs: 47 W |
Single 75 W AC input: 47 W Dual 75 W AC inputs: 49 W Single 150 W AC input: 49 W Dual 150 W AC inputs: 56 W Single 150 W DC input: 58 W Dual 150 W DC inputs: 60 W |
Single 75 W AC input: 29 W Dual 75 W AC inputs: 32 W Single 150 W AC input: 32 W Dual 150 W AC inputs: 39 W Single 150 W DC input: 35 W Dual 150 W DC inputs: 44 W |
Single 75 W AC input: 44 W Dual 75 W AC inputs: 46 W Single 150 W AC input: 46 W Dual 150 W AC inputs: 52 W Single 150 W DC input: 57 W Dual 150 W DC inputs: 59 W |
| MTBF(Year) | 131.97 | 151.28 | 150.86 | 115.68 |
| MTTR(Hour) | 1 | 1 | 1 | 1 |
| Item | S5560S-28S-PWR-EI | S5560S-52S-PWR-EI | S5560S-28F-EI | S5560S-52F-EI |
| Port Switching capacity | 128Gbps | 176Gbps | 128Gbps | 176Gbps |
| Box Switching capacity | 598Gbps | |||
| Packet forwarding rate | 96 Mpps | 132 Mpps | 96 Mpps | 132 Mpps |
| CPU | 1 Core, 800MHz | |||
| Dimensions (H × W × D) | 43.6 × 440 × 460 mm (1.72 × 17.32 × 18.10 in) | 43.6 × 440 × 460 mm (1.72 × 17.32 × 18.10 in) | 43.6 × 440 × 360 mm (1.72 × 17.32 × 14.17 in) | 43.6 × 440 × 360 mm (1.72 × 17.32 × 14.17 in) |
| Weight | ≤ 8.5 kg (18.74 lb) | ≤ 9.5 kg (20.94 lb) | ≤ 6 kg (13.22 lb) | ≤ 8.5 kg (18.74 lb) |
| Flash/SDRAM | 512MB/512MB | |||
| Management Ethernet ports | 1 | |||
| Console ports |
1 × RJ-45 console port 1 × Micro-USB port Only the Micro-USB port is available if you connect both ports. |
|||
| Service ports |
24 × 10/100/1000Base-T autosensing POE+ Ethernet ports (including 4 combo interfaces) 4 × 10G SFP+ ports |
48 × 10/100/1000Base-T autosensing POE+ Ethernet ports 4 × 10G SFP+ ports |
24 × 100/1000BASE-X SFP Ports (including 8 combo interfaces) 4 × 10G SFP+ ports |
48 × 100/1000BASE-X SFP Ports 4 × 10G SFP+ ports 4 × GE SFP ports |
| Stacking bandwidth | 80Gbps | |||
| Rated input voltage |
AC: 100 VAC to 240 VAC @ 50 Hz/60 Hz DC: –36 VDC to –72 VDC |
|||
| Min. power consumption | 27W | 37W |
Single 75 W AC input: 15 W Dual 75 W AC inputs: 17 W Single 150 W AC input: 18 W Dual 150 W AC inputs: 23 W Single 150 W DC input: 18 W Dual 150 W DC inputs: 22 W |
Single 75 W AC input: 21 W Dual 75 W AC inputs: 24 W Single 150 W AC input: 25 W Dual 150 W AC inputs: 30 W Single 150 W DC input: 26 W Dual 150 W DC inputs: 32 W |
| Max. power consumption |
Single 360 W AC input: 334 W (Including 280W POE) Dual 360 W AC inputs: 678 W (Including 600W POE) Single 560 W DC input: 573W (Including 480W POE) Dual 560 W DC inputs: 918 W (Including 480W POE) Single 720 W AC input: 676 W (Including 600W POE) Dual 720 W AC inputs: 905W (Including 810W POE) Single 1110 W AC input: 898W (Including 810W POE) Dual 1110 W AC inputs: 905 W (Including 810W POE) |
Single 360 W AC input: 354 W (Including 280W POE) Dual 360 W AC inputs: 685 W (Including 600W POE) Single 560 W DC input: 593W (Including 480W POE) Dual 560 W DC inputs: 1060 W (Including 900W POE) Single 720 W AC input: 695 W (Including 600W POE) Dual 720 W AC inputs: 1460W (Including 1320W POE) Single 1110 W AC input: 1019W (Including 900W POE) Dual 1110 W AC inputs: 1850 W (Including 1680W POE) |
Single 75 W AC input: 47 W Dual 75 W AC inputs: 49 W Single 150 W AC input: 48 W Dual 150 W AC inputs: 55 W Single 150 W DC input: 51 W Dual 150 W DC inputs: 57 W |
Single 75 W AC input: 47 W Dual 75 W AC inputs: 49 W Single 150 W AC input: 49 W Dual 150 W AC inputs: 56 W Single 150 W DC input: 58 W Dual 150 W DC inputs: 60 W |
| MTBF(Year) | 89.35 | 61.87 | 77.58 | 153.41 |
| Vlan table | 4K | |||
| Operating temperature | 0ºC to 45ºC (32°F to 113°F) | |||
| Storage temperature | -40℃ to 70℃(-40℉ to 158℉) | |||
| Operating & storage humidity | 5% RH to 95% RH, non-condensing | |||
| SDN/OpenFlow |
OpenFlow 1.3 Multiple controllers (equal/master/slave controller role) Concurrent processing of multiple flow tables Group table Meter |
|||
| Link aggregation |
1G/10G/40G port aggregation Static aggregation Dynamic aggregation Multichassis link aggregation |
|||
| Port features |
802.3x flow control (full-duplex) Storm suppression based on port bandwidth percentage Storm suppression based on PPS Storm suppression based on BPS Broadcast traffic/Multicast traffic/Unknown unicast traffic suppression |
|||
| Jumbo frame | 10,000 | |||
| MAC address table |
16K MAC address entries Blackhole MAC address MAC learning limit |
|||
| VLAN |
Port-based VLAN MAC-based VLAN Protocol-based VLAN IP subnet based VLAN QinQ and flexible QinQ VLAN mapping Voice VLAN MVRP |
|||
| Loop-free redundant Layer 2 topology |
STP/RSTP/MSTP/PVST+/RPVST+ Smart Link RRPP G.8032 Ethernet ring protection switching (ERPS) |
|||
| DHCP |
DHCP client DHCP snooping DHCP relay DHCP server DHCP snooping Option 82/DHCP relay Option 82 |
|||
| IRF2 |
IRF2 Distributed device management, distributed link aggregation, and distributed resilient routing Stacking through standard Ethernet interfaces Local device stacking and remote device stacking Support up to 9 devices stacking |
|||
| IP routing |
12K IPV4 routing entries Static routing RIPv1/v2 and RIPng OSPFv1/v2/v3 BGP and BGP4+ for IPv6 IS-IS VRRP/VRRPv3 |
|||
| IPv6 |
Neighbor Discovery (ND) PMTU IPv6-Ping, IPv6-Tracert, IPv6-Telnet, and IPv6-TFTP Manual tunnel 6to4 tunnel ISATAP tunnel |
|||
| Multicast |
IGMP Snooping v1/v2/v3 and MLD Snooping v1/v2 PIM Snooping MLD Proxy Multicast VLAN IGMP v1/v2/v3 and MLD v1/v2 PIM-DM, PIM-SM, and PIM-SSM MSDP and MSDP for IPv6 MBGP and MBGP for IPv6 |
|||
| Mirroring |
Flow mirroring N:4 port mirroring Local port mirroring and remote port mirroring |
|||
| OAM |
802.1ag 802.3ah |
|||
| QoS/ACL |
Layer 2 to Layer 4 packet filtering Traffic classification based on source MAC, destination MAC, source IP, destination IP, TCP/UDP port number, and VLAN Time range-based ACL Bi-directional ACLs (inbound and outbound) VLAN-based ACL issuing Rate limit for receiving and transmitting packets (a minimum CIR of 8 Kbps) Packet redirection 802.1p priority and DSCP priority Committed Access Rate (CAR) Eight queues per port (including the CPU port) Flexible queue scheduling algorithms based on both port and queue, including SP, WRR, WFQ, SP+WRR, and WDRR WRED |
|||
| Security |
Hierarchical user management and password protection 802.1X authentication and centralized MAC address authentication Guest VLAN RADIUS authentication HWTACACS authentication SSH 2.0 Port isolation Port security Portal authentication EAD DHCP snooping Dynamic ARP detection BPDU guard and root guard uRPF IP/Port/MAC binding Plaintext authentication and MD5 authentication for OSPF and RIPv2 packets Public Key Infrastructure (PKI) IP Source Guard |
|||
| Management and maintenance |
Loading and upgrading through XMODEM/FTP/TFTP Configuration through CLI, Telnet, and console ports SNMPv1/v2/v3 Web network management Remote Monitoring (RMON) alarm, event, and history recording IMC network management system System log, alarming based on severity, debugging information output NTP Power, fan, and temperature alarming Ping and Tracert Virtual Cable Test (VCT) Device Link Detection Protocol (DLDP) LLDP, LLDP-MED Loopback detection |
|||
| Power saving |
802.3az EEE Automatic port power-down Scheduled port power-down (schedule job) |
|||
| IEEE |
IEEE 802.3x IEEE 802.3u, IEEE 802.3z, IEEE 802.3az, IEEE 802.3ab, IEEE 802.3ah IEEE 802.3ad IEEE 802.3af IEEE 802.3at IEEE 802.3bt IEEE 802.3bz IEEE 802.1p IEEE 802.1x IEEE 802.1q IEEE 802.1d IEEE 802.1w IEEE 802.1s IEEE 802.1ax IEEE 802.1ag |
|||
| EMC |
FCC Part 15 Subpart B CLASS A ICES-003 CLASS A VCCI CLASS A CISPR 32 CLASS A EN 55032 CLASS A AS/NZS CISPR32 CLASS A CISPR 24 EN 55024 EN 61000-3-2 EN 61000-3-3 ETSI EN 300 386 for telecommunications center installations GB/T 9254 YD/T 993 |
|||
| Safety |
UL 60950-1 CAN/CSA C22.2 No 60950-1 IEC 60950-1 EN 60950-1 AS/NZS 60950-1 FDA 21 CFR Subchapter J GB 4943.1 |
|||
Notices:
1. Open the packaging, check the products carefully, and take them gently.
